The Ball Balancing PID System is a cheap multidisciplinary project I developed in 2018 during my BSc in Automation Engineering. This system holds a ball in balance on a 2-axis tiltable plate. A webcam is placed above the system, connected to a computer running a real time computer vision algorithm for ball detection. A feedback control law is computed by means of 2 PID controllers. Finally, a microcontroller actuates a pair a of servo motors, stabilizing the ball over the plate.

The project is designed to be modular; there are 4 main stand-alone modules:

1. Computer Vision Module: acquires and preprocess ball position using OpenCV libs.

2. PID Module: filters and computes the control input through a digital PI-D.

3. Serial Communication Module: it provides communication beetwen PC and microcontroller.

4. Actuation Module: embedded software running on microcontroller. It uses interrupts to detects incoming packets and drives servo motors.

• microcontroller: ATmega2560
• Servos: DS3218MG 5V-6.8V
• USB camera: 640x480
• Battery pack: 6V, 2850mAh

• OS: Ubuntu 16.04
• Language: C/C++
• Compilers: gcc 5.4.0, avr-gcc 4.9.2
• Additional libs: OpenCV 3.4.1

General overview:

PC side detailed workflow:

Double PID control scheme:

Compile and run with one of this flag:

• Standard mode: better performance but minimal GUI

"./run -s"

• Setting mode: set pid gains and computer vision parameters

./run -settings

• Debug mode: start debug mode: a better GUI and print utilities, little bit slower than standard mode

./run -debug

• Manual mode: platform can be controlled directly from terminal.

./run -manual

note: one and only one flag can be used
